Lead- Acid Battery Characteristics Training Systems
Lead- Acid Battery Characteristics Training Systems - Image 2
,

Lead- Acid Battery Characteristics Training Systems

SKU BB_045

Price on request
In stock
Request a quote

Send us the quantity and delivery location and we'll come back with pricing, usually the same working day.

Description

Branch Electrical
Nominal Voltage 12V
Equipment Type Trainer Kit
Training Level ITI, Skill Dev, Engineering, Diploma
Power Supply 230 V AC
Mount Type Table Top
Display Type LCD
No Of Experiments Up To 5
Manual Included Yes
Rated Capacity 7 Ah – 100 Ah (depending on model)
Input Power for Charging 12 V – 24 V DC (adjustable)
Display / Indicators Digital / Analog voltmeter, ammeter, SOC indicators
The Lead-Acid Battery Characteristics Training System is a lab-based platform designed to help learners understand the performance, charging, and discharging characteristics of lead-acid batteries. It provides a hands-on training environment for analyzing voltage, current, capacity, efficiency, and state-of-charge under various load conditions. This system is widely used in engineering labs, EV training centers, and energy storage education.

Key Features

  • Demonstrates charging, discharging, and efficiency characteristics of lead-acid batteries.
  • Supports different load conditions for performance analysis.
  • Real-time measurement of voltage, current, power, and capacity.
  • Includes safety features: over-voltage, over-current, and short-circuit protection.
  • Lab-friendly, tabletop design suitable for classroom demonstrations.
  • Allows learners to study effect of depth-of-discharge (DoD) and load variation on battery life and performance.
  • Ideal for EV training, UPS studies, and general battery education.
